Description
- Brand Name: Canon
- Set Type: Fuselage
- Origin: Mainland China
- Video Resolution: Full HD (1920×1080)
- Effective MegaPixel: 20MP
- Supporting Language: Russian,English,Simplified Chinese,Traditional Chinese
- Special Feature: Swivel/Tilt LCD
- Sensor Size (inches): APS-C
- Certification: CE
Type Autofocus with built-in flash/
Automatic exposure single-lens reflex digital camera
Recording media SD memory card, SDHC memory card, SDXC memory card
※ Compatible with UHS-I
Image sensor size Approx. 22.5×15.0 mm
Compatible lenses Canon EF series lenses (including EF-S, excluding EF-M lenses)
(35mm equivalent focal length is about 1.6 times the focal length of the lens)
Lens mount Canon EF mount
image sensor
Type CMOS image sensor
Effective pixels about 20.2 million pixels
※The number of effective pixels is rounded to the nearest 10,000 digits
Aspect ratio 3:2
Dust removal function Automatic, manual, add dust removal data
system of record
Recording System Camera File System Design Rule 2.0
(Design rule for Camera File System 2.0)
Image type JPEG, RAW (14-bit, Canon original)
Can record RAW+JPEG at the same time
Recording pixels L (large): Approx. 20 million pixels (5472 x 3648)
M (Medium): Approx. 8.9 million pixels (3648 x 2432)
S1 (Small 1): Approx. 5 million pixels (2736 x 1824)
S2 (Small 2): Approx. 2.5 million pixels (1920 x 1280)
S3 (Small 3): Approx. 350,000 pixels (720 x 480)
RAW: Approx. 20 million pixels (5472 x 3648)
M-RAW: Approx. 11.2 million pixels (4104 x 2736)
S-RAW: Approx. 5 million pixels (2736 x 1824)
Create/Select Folder Yes
File numbering Continuous numbering, auto reset, manual reset
Image processing during shooting
Picture Style Auto, Standard, Portrait, Landscape, Neutral, Reliable, Monochrome, User Defined 1-3
Basic + Shooting with selected ambience effects, shooting according to lighting or scene type
White Balance Auto, Preset (Daylight, Shade, Cloudy, Tungsten Light, White Fluorescent Light, Flash), User Defined, Color Temperature Setting (Approx. 2500-10000K) with White Balance Correction and White Balance Bracketing
※ With flash color temperature information transmission
Noise reduction Can be used for long exposures and high ISO sensitivity shots
Automatic image brightness correction Automatic brightness optimization
Highlight tone priority Yes
Lens aberration correction Peripheral illumination correction, chromatic aberration correction
viewfinder
Type Eye Level Pentamirror
Field of view: about 98% vertical/horizontal (eye point about 22mm)
Magnification: about 0.95 times (-1 m-1, using 50mm lens to focus at infinity)
Eye point Approx. 22 mm (-1 m-1 from the center of the eyepiece lens)
Built-in diopter adjustment Approx. -3.0 to +1.0 m-1 (dpt)
Focusing screen Fixed
Grid line display Yes
Electronic level can be displayed before and after shooting
Mirror Quick return
Depth of Field Preview Available
auto focus
Type TTL Auxiliary Image Coincidence, Phase Detection
AF points: 19 points (all are cross-type corresponding to F5.6, and the center is dual-cross-type AF corresponding to F2.8)
※Except some lenses
Focus brightness range EV -0.5 – 18 (center AF point, 23°C, ISO 100)
Focus Mode One-Shot AF, AI Servo AF, AI AF, Manual Focus
AF area selection mode Single-point AF (manual selection), Zone AF (manual selection) 19 AF points are automatically selected
AI Servo AF features Tracking sensitivity, acceleration/deceleration tracking
AF fine-tuning AF fine-tuning (uniform adjustment for all lenses or per-lens adjustment)
AF-assist beam A short burst of fire from the built-in flash
exposure control
Metering mode 63-zone TTL full-aperture metering
・Evaluative metering (linked to all AF points)
・Partial metering (approximately 7.7% of the area in the center of the viewfinder)
・Spot metering (approximately 3.0% of the area in the center of the viewfinder)
・Center-weighted average metering
Metering range EV 1 to 20 (23°C, with EF 50mm f/1.8 II lens, ISO 100)
Exposure Control Program AE (Scene Intelligent Auto, Flash Disable, Creative Auto, Special Scene Modes (Portrait, Landscape, Macro, Sports, Night Portrait, Handheld Night Scene, HDR Backlight Control), Program), Shutter Priority AE, Aperture Priority Auto exposure, manual exposure, bulb exposure
ISO sensitivity
(Recommended Exposure Index) Basic Zone Modes: Automatically set between ISO 100 – 6400
*Landscape: Automatically set between ISO 100-1600, Handheld Nightscape: Automatically set between ISO 100-12800
Creative Zone modes: Auto ISO, manual setting between ISO 100 – 12800 (in 1/3-stop or 1-stop increments), or ISO sensitivity expanded to “H” (equivalent to ISO 25600)
ISO sensitivity setting ISO sensitivity range, auto ISO range, auto ISO minimum shutter speed can be set
Exposure Compensation Manual: Adjustable in 1/3 or 1/2-stop increments between ±5 stops
AEB: Adjustable in 1/3 or 1/2-stop increments between ±3 stops
(Can be combined with manual exposure compensation)
AE Lock Auto: Applied when focus is achieved in One-Shot AF mode using evaluative metering
Manual: Via the AE lock button
HDR shooting
Dynamic range adjustment Auto, ±1EV, ±2EV, ±3EV
Automatic Image Alignment Yes
multiple exposure
Multiple exposures 2-9 exposures
Multiple Exposure Control Addition, Average
shutter
Type Electronically controlled focal plane shutter
Shutter speed 1/8000 to 30 sec, Bulb (total shutter speed range. Available range varies with shooting mode), Flash sync speed 1/250 sec
flash
Built-in flash Retractable, automatic pop-up flash
Guide number: Approx. 12 (ISO 100 in meters)
Flash coverage: about 17mm lens angle of view
Recycle time is about 3 seconds
With wireless master function
External Speedlite EX-series Speedlite (can set the flash function with the camera)
Flash metering E-TTL II autoflash
Flash exposure compensation ±3 stops in 1/3 or 1/2 stops
FE lock Yes
PC terminal None
Drive System
Drive mode Single shooting, high-speed continuous shooting, low-speed continuous shooting, silent single shooting, silent continuous shooting, 10-second Selfie/remote control, 2-second Selfie/remote control
Continuous shooting speed High-speed continuous shooting: up to about 7 frames per second
Low-speed continuous shooting: up to about 3 frames per second
Silent continuous shooting: up to about 3 frames per second
Maximum number of continuous shots JPEG large/fine: about 40 shots (about 65 shots)
RAW: Approx. 15 (Approx. 16)
RAW+JPEG Large/Fine: Approx. 8 (Approx. 8)
* Figures based on Canon’s testing standards using 8GB memory cards (ISO 100 and “Standard” Picture Style)
* Values in parentheses apply to UHS-I compatible 8GB memory cards based on Canon’s testing standards
Live View Shooting
Aspect ratio settings 3:2, 4:3, 16:9, 1:1
Focusing method Dual Pixel CMOS AF (full pixel dual-core CMOS AF) / contrast detection method (face + tracking, free movement multi-point, free movement 1 point)
Phase difference detection method (fast mode)
Manual focus (approximately 5x, 10x magnification can be confirmed)
Continuous autofocus Yes
Focus brightness range EV 1 to 18 (23°C, ISO 100)
Metering modes Evaluative metering (315 areas), partial metering (about 10.3% of the Live View screen), spot metering (about 2.6% of the Live View screen), center-weighted average metering
Metering range EV 0 ~ 20 (23℃, using EF 50mm f/1.4 USM lens, ISO 100)
Creative filters Grainy black and white, soft focus, fisheye effect, oil painting effect, watercolor painting effect, toy camera effect, miniature effect
Silent Shooting Available (Modes 1 and 2)
Touch shutter with
Display grid lines 3 types
short film shooting
Movie compression MPEG-4 AVC/H.264
Variable (average) bit rate
Audio recording format Linear PCM
Recording format MOV
Recording size and frame rate 1920×1080 (Full HD): 30p/25p/24p
1280×720 (HD): 60p/50p
640×480 (SD): 30p/25p
*30p: 29.97 fps, 25p: 25.00 fps, 24p: 23.98 fps, 60p: 59.94 fps, 50p: 50.00 fps
Compression method ALL-I (I only), IPB
File size 1920×1080 (30p/25p/24p)/IPB: about 235MB/min
1920×1080 (30p/25p/24p)/ALL-I: Approx. 685MB/min
1280×720 (60p/50p)/IPB: about 205MB/min
1280×720 (60p/50p)/ALL-I: Approx. 610MB/min
640×480 (30p/25p)/IPB: about 78MB/min
※ Memory card read/write speed required for movie shooting:
IPB: at least 6MB per second, ALL-I: at least 20MB per second
Focus method Same as Live View shooting
※ Quick mode cannot be used during movie shooting
Servo AF Yes
Metering modes Center-weighted average and evaluative metering using the image sensor
* Automatically set by focus mode
Metering range EV 0 – 20 (23°C, with EF 50mm f/1.4 USM lens, ISO 100)
Exposure Control Program AE and Manual Exposure for Movies
Exposure compensation Adjustable in 1/3-stop increments between ±3 stops (±5 stops for still images)
ISO sensitivity
(Recommended Exposure Index) When shooting with AE: Automatically set between ISO 100 – 6400, expandable to “H” (equivalent to ISO 12800) in Creative Zone modes
When shooting with manual exposure: Automatically set between ISO 100 – 6400, manually set between ISO 100 – 6400 (in 1/3-stop or full-stop increments), expandable to “H” (equivalent to ISO 12800)
Digital zoom can be set to about 3-10 times zoom
timecode support
Drop Frame Compatible with 60p/30p
Video snapshot can be set to 2s/4s/8s
Recording with built-in stereo microphone
External stereo microphone terminal
Adjustable recording level, with wind suppression function, with attenuator function
Display grid lines Three types
Still image shooting Yes
LCD monitor
Type TFT color LCD monitor
Monitor size and dots Widescreen, 3.0″ (3:2), approx. 1.04 million dots
Brightness adjustment Manual (7 levels)
Electronic level Displays the horizontal level in 1° units
25 interface languages (including Simplified Chinese)
Touch screen technology Capacitance method
Function introduction can be displayed
playback
Image display formats Single image display, single image + information display (basic information, shooting information, histogram), 4-image index, 9-image index
AF point display Yes
Three types of grid line display
Magnified display about 1.5 times – 10 times
Image browsing methods Single image, jump (by 10 or 100 images, shooting date, folder, movie, still image, rating)
Highlight Warning Overexposed highlight areas flicker
Image rotation can be
Rating Available
Movie playback Allowed (LCD monitor, video/audio output, HDMI output)
Built-in speaker
Slideshow All images, by date, folder, clip, still image or rating
Background music can be selected for slideshow and movie playback
Image protection yes
Post-processing of images
In-camera RAW image processing Brightness correction, white balance, Picture Style, Auto Lighting Optimizer, high ISO sensitivity noise reduction, JPEG image-recording quality, color space, peripheral illumination correction, distortion correction, and chromatic aberration correction
resize possible
Creative filters Grainy black and white, soft focus, fisheye effect, oil painting effect, watercolor painting effect, toy camera effect, miniature effect
direct print
Compatible Printers PictBridge Compatible Printers
Printable images JPEG and RAW images
Print command Compatible with DPOF version 1.1
custom function
23 custom functions
Custom shooting modes are registered under the C position of the mode dial
Sign up for my menu with
Copyright information This information can be entered and included
interface
Audio/Video Out/Digital Terminal Analog Video (NTSC/PAL Compatible)/Stereo Audio Out
For computer communication and direct printing (equivalent to Hi-Speed USB)
HDMI mini output terminal Type C (automatic resolution switching), CEC compliant
External microphone input terminal 3.5mm diameter stereo mini jack
Remote control terminal for remote release RS-60E3
Wireless Remote Control Remote Control RC-6
Wireless LAN
Compliant with standard IEEE802.11b/g/n
Transmission mode DS-SS modulation (IEEE802.11b), OFDM modulation
(IEEE802.11g/n)
Transmission range about 30 meters
※When there are no obstacles or obstructions between the transmitting and receiving antennas, and when there is no radio wave interference from other equipment.
※The access point needs to have a large antenna with high performance
Transmission Frequency (Central Frequency) 2412-2462MHz: Channels 1-11
Connection method Infrastructure mode*, camera access point mode, peer-to-peer mode (connecting the camera)
※Support Wi-Fi protected settings
Security Authentication methods: Open, Shared Key, WPA-PSK and WPA2-PSK
Encryption: WEP, TKIP and AES
power supply
Battery Battery LP-E6 (1 pc)
* Can use AC power via AC Adapter Kit ACK-E6
* When the battery case and handle BG-E14 is installed, AA size (AA/LR6) batteries can be used
Battery Information Displays remaining power, number of shutter releases, charging performance and battery registration
Battery shooting capability
(Based on CIPA test standards) Shooting with viewfinder: Approx. 920 at 23°C, 850 at 0°C
Shooting with Live View: Approx. 210 at 23°C, 200 at 0°C
※ Use a fully charged battery LP-E6
Movie shooting time Approx. 1 hour 20 minutes at 23°C
